Electronic Products SMT / DIP PCB Assembly


General information

Base material:FR4

Layer:2

Name:Amplifier PCB assembly

Surface finish:HASL lead free

Copper thickness:1OZ

Test: Flying probe test, X-ray Inspection,AOI (Automated Optical Inspection)

ICT (In-Circuit Test)/Functional Testing

PCB Assembly General Manufacturing Capabilities:

Type of Assembly

THD (Thru-Hole Device), SMT (Surface-Mount Technology), SMT & THD mixed, Double-sided SMT and THD assembly.

Solder Type

Water Soluble Solder Paste, Leaded process and Lead-Free (RoHS)

Components

Passives parts, smallest size 0201

BGA, uBGA, QFN, POP, and Leadless chips

Fine Pitch to 0.8Mils;

BGA Repair and Reball; Part Removal and Replacement

Connectors and terminals

Bare Board Size

Smallest:0.25’’x 0.25’’ (6.35mm x 6.35mm)

Largest: 20’’ x 20’’ (508mm x 508mm)

Min. IC Pitch

0.012’’ (0.3mm)

QFN Lead Pitch

0.012’’ (0.3mm)

Max. BGA size

2.90’’ x 2.90’’ (74mm x 74mm)

Type of Service

Turn-key, partial turn-key or consignment

Testing

X-ray Inspection

AOI (Automated Optical Inspection)

ICT (In-Circuit Test)/Functional Testing

Component packaging

Reels, cut tape, Tube and tray, Loose parts and bulk


PCB Assembly Concept:

PCBA is the abbreviation of printed circuit board + Assembly, that is to say, the PCB bare board through the SMT, and then through the whole process of the DIP plug-in, referred to as the PCBA, which is commonly used in China, and the standard in Europe and America is PCB 'A, is added to the ramp point. This is called the official idiom, we communicate with foreign customers or when the promotion, they often ask what is PCBA.

A printed circuit board (PCB) mechanically supports and electrically connects electronic components using conductive tracks, pads and other features etched from copper sheets laminated onto a non-conductive substrate. Components – capacitors, resistors or active devices – are generally soldered on the PCB. Advanced PCBs may contain components embedded in the substrate.

PCBs can be single sided (one copper layer), double sided (two copper layers) or multi-layer (outer and inner layers). Conductors on different layers are connected with vias. Multi-layer PCBs allow for much higher component density.

FR-4 glass epoxy is the primary insulating substrate. A basic building block of the PCB is an FR-4 panel with a thin layer of copper foil laminated to one or both sides. In multi-layer boards multiple layers of material are laminated together.

Printed circuit boards are used in all but the simplest electronic products. Alternatives to PCBs include wire wrap and point-to-point construction. PCBs require the additional design effort to lay out the circuit, but manufacturing and assembly can be automated. Manufacturing circuits with PCBs is cheaper and faster than with other wiring methods as components are mounted and wired with one single part.

A minimal PCB with a single component used for easier modeling is called breakout board.


PCB/PCBA Order tips:

A. PCB order: Please provide Gerber File and manufacturing specifications.

B. PCBA order: Please provide Gerber File, Manufacturing specification, BOM list and Pick & Place/XY file.

C. Reverse engineering and PCB copy service can be supplied with your PCB sample.

D. PCB design need detail information about the function or supply the drawing.

E. Any further questions, welcome to contact us by sending email.

.

Main PCBA Equipments

ITEM

Device Name

Model

Brand Name

Qty

Remarks

1

Full Automatic Screen Printer

DSP-1008

DESEN

8



2

SMT Machine

YG200

YAMAHA

5



8 SMT Line

3

SMT Machine

YV100XG

YAMAHA

3

4

SMT Machine

YG100XGP

YAMAHA

19

5

SMT Machine

YV88

YAMAHA

5

6

Reflow Soldering

8820SM

NOUSSTAR

4



7

Reflow Soldering

XPM820

Vitronics Soltec

3



8

Reflow Soldering

NS-800 II

JT

1



9

Solder Paste Inspection

REAL-Z5000

REAL

1



10

Automatic Optical Inspection System

B486

VCTA

3



11

Automatic Optical Inspection System

HV-736

HEXI

5



12

X-Ray

AX8200

UNICOMP

1



13

BGA Re-work

MS8000-S

MSC

1



14

Universal 4*48-pindrive concurrent multiprogramming system

Beehive204

ELNEC

3



15

Automatic Plug-In machines

XG-3000

SCIENCGO

2



16

Automatic wave soldering system

WS-450

JT

1

3 DIP LINE

17

Automatic wave soldering system

MS-450

JT

2
